1.Parameter:
Model:6YL-180
Dimensions:2700*2000*2700mm
Weight:1980kg
3 Phase 380v Power:30kw/37kw
Processing Volume:400-750kg/h
2.Materials:
Sesame,Peanut,Sunflower,Walnut,Macadamia,Hemp seed,Cocoa bean,Pine nuts,Cashew nuts,Perilla seeds,Safflower seed,Passion fruit seeds,Coconut,Sacha inchi,Prickly ash seedonion seeds,Flaxseed,Rapeseed,Castor,Avocado,Custard apple seeds,Chest nut,Neem,Mango kernel,Black soldier fly and so on.
3.Introduction:
Three-Stage Press. The multi-stage pressing screw ensures complete oil extraction. The secondary cake feeder system allows for a second press to maximize oil utilization from valuable feedstocks. The resulting specialty oils are of high quality, and the residual cakes can be explored for niche applications in food ingredients or premium organic fertilizers.

1.Parameter:
Model:6YY-185
Dimensions:600*880*1150mm
Weight:590kg
Power:2.2kw/1.1kw
Voltage:220v/380v
Oil Cake Diameter:185mm
Cylinder Volume:7.2L
Working Pressure:60mpa
Capacity:4kg/batch
2.Materials:
Sesame,Peanut,Sunflower,Walnut,Macadamia,Hemp seed,Cocoa bean,Pine nuts,Cashew nuts,Perilla seeds,Safflower seed,Passion fruit seeds,Coconut,Sacha inchi,Prickly ash seedonion seeds,Flaxseed,Rapeseed,Castor,Avocado,Custard apple seeds,Chest nut,Neem,Mango kernel, and so on.
3.Introduction:
This hydraulic oil press model integrates advanced pressurization technology with a robust two-stage safety protection system to guarantee secure and stable operation. Its core is built for strength and precision: the main unit features a uniform hard-chrome plating, while the hydraulic cylinder is precision-engineered for exceptional high-pressure bearing capacity. A significant advantage is its superior working pressure of 60 MPa, which thoroughly presses raw materials to achieve a remarkably higher oil yield compared to industry standards. Perfect for oils like sesame, peanut, and walnut, it also transforms the residual cake into valuable animal feed or organic fertilizer, creating additional profit streams.

Our factory's refining machines can be customized and configured according to customer requirements. Please contact me for more information.
Supporting equipment: Dephosphorization and deacidification tank, deodorization, plate and frame oil filter.
This fully automatic stainless steel refining equipment is designed for small to medium-scale operations, integrating key processes into a streamlined, efficient system. With a capacity of 300kg per 6-hour working period, it efficiently transforms crude oil into high-quality, market-ready products.
It features manual temperature control via displayed meters for precise operation and includes a plate and frame oil filter for clarity. The refined oil is transparent, stable (no sedimentation or heating foam/smoke), and ready for bottling and direct sale.
Ideal for small oil mills, specialty oil producers, and facilities processing biodiesel feedstock, this unit supports a wide range of oils—from bulk oils like soybean, rapeseed, and sunflower oil to high-value oils such as walnut and rice bran oil. It enables the miniaturization of industrial-scale refining, offering a reliable solution for producing edible, cosmetic, and pharmaceutical-grade oils with consistent, safe, and stable operation.
